BSRP1300 bottom wideband sanding machine_Qingdao sanding machine manufacturer

ProductYour current location: Home > Bottom broadband sander

BSRP1300 bottom wideband sanding machine

Detailed description

Features:

BSRP1300 sanding machine is mainly used in solid wood panels, door panels, flooring and wood-based panel sanding, can also be on the sand with the top, the end of sand production line, adapted to mass production.

BSRP1300A sanding machine is mainly used for floor, solid wood, furniture, wood bench with a wooden sand.

Technical Parameters:

Model	BSRP1300	BSRP1300A
Processing width	40-1300mm	40-1300mm
Processing thickness	3-100mm	3-100mm
Processing length	≥300mm	≥300mm
Feeding speed	6-30m/min	6-30m/min
Belt size ( W x P )	1330x2500mm	1330x2500mm
Main motor power	37Kw	37Kw;22kw
Feed motor power	3.7kw	3.7kw
Lift motor power	0.75kw	1.5kw
Working pressure	0.55Mpa	0.55Mpa
Compressed air consumption	0.15m³/min	1m³/min
Air intake	9000m³/h	12000m³/h
Suction wind speed	22-25m/s	22-25m/s
Dimensions (L x W x H)	2250x2130x2345mm	3050x2130x2300mm
Net weight	4000kg	6200kg
