Detailed description
Technical features
|
|
SRP600-1
|
SRP600-2
|
SRP600Q
|
|
Working width
|
40-600mm
|
40-600mm
|
40-600mm
|
|
Working thickness
|
3-125mm
|
3-125mm
|
3-125mm
|
|
Working length
|
≥500mm
|
≥500mm
|
≥450mm
|
|
No.1 abrasive belt speed
|
18m/s
|
18m/s
|
1-18m/s
|
|
No.2 abrasive belt speed
|
12m/s
|
12m/s
|
|
|
Feed speed
|
4-16m/min
|
4-16m/min
|
4-16m/min
|
|
Size of abrasive belt(WxP)
|
630x1900mm
|
630x1900mm
|
630x1900mm
|
|
Total motor power
|
18.62kw
|
20.62kw
|
7.62kw
|
|
Main motor
|
11kw,5.5kw
|
11kw,7.5kw
|
5.5kw
|
|
Working air pressure
|
0.55Mpa
|
0.55Mpa
|
0.55Mpa
|
|
Consumption of compressed air
|
0.1m3/min
|
0.1m3/min
|
0.3m3/min
|
|
Volume of sucked air
|
4500m3/h
|
4500m3/h
|
4500m3/h
|
|
Speed of sucked air |
25-30m/s
|
25-30m/s
|
25-30m/s
|
|
Overall dimension{LxWxH)
|
1850x1190x1970mm
|
1850x1190x1970mm
|
1850x1190x1970mm
|
|
Net weight
|
1600kg
|
1600kg
|
1400kg
|
