Detailed description
Technical features
|
|
SPRU1300
|
SPRU600
|
|
Working width
|
40-1300mm
|
40-600mm
|
|
Working thickness
|
3-100mm
|
3-100mm
|
|
Working length
|
≥590mm
|
≥500mm
|
|
1#No1 abrasive belt speed
|
19m/s
|
18m/s
|
|
2#No1 abrasive belt speed
|
18m/s
|
12m/s
|
|
Feed speed
|
4-20m/min
|
4-16m/min
|
|
Size of abrasive belt(WxP)
|
1330x2500mm
|
630x1900mm
|
|
Total motor power
|
77.12kw
|
30.32kw
|
|
Main motor
|
22kw,30kw,18.5kw
|
11kw,11kw,5.5kw
|
|
Working air pressure
|
0.55Mpa
|
0.55Mpa
|
|
Consumption of compressed air
|
0.1m3/min
|
0.1m3/min
|
|
Volume of sucked air
|
12000m3/h
|
4500m3/h
|
|
Speed of sucked air |
25-30m/s
|
25-30m/s
|
|
Overall dimension{LxWxH)
|
3090x2060x2310mm
|
2238x1280x2012mm
|
|
Net weight
|
5200kg
|
2500kg
|
