Detailed description
Technical Parameters
|
|
SAF1300A
|
SAF1300
|
|
|
Processing width
|
40-1300mm
|
40-1300mm
|
|
|
Processing thickness
|
3-110mm
|
3-110mm
|
|
|
Processing length
|
>200mm
|
>200mm
|
|
|
1 # sand frame belt speed
|
5-15m/min
|
2-12m/min
|
|
|
2 # sand frame belt speed
|
5-15/s
|
4-12/s
|
|
|
Belt size
|
1330x2200mm
|
1330x2200mm
|
|
|
Conveyor belt size
|
1300x4500mm
|
1300x5000mm
|
|
|
1 # sand frame
|
15
|
15
|
|
|
2 # sand frame
|
15
|
15
|
|
|
Motor power (KW)
|
Conveyor
|
2..2
|
3.7
|
|
Conveyor bed lift drive
|
0.75
|
0.75
|
|
|
Polishing roller
|
4
|
4
|
|
|
|
Brush roll
|
0.37
|
0.37
|
|
High pressure air blower
|
5.5
|
5.5
|
|
|
Compressed air
|
Working pressure
|
0.55Mpa
|
0.55Mpa
|
|
Consumption
|
0.2m3/min
|
0.1m3/min
|
|
|
Optional dust removal device
|
Air intake
|
10000m3/h
|
9000m3/h
|
|
Static pressure
|
1300Pa
|
1300Pa
|
|
|
Suction wind speed
|
25-30m/s
|
22-25m/s
|
|
|
Dimensions (L x W x H)
|
2800x2040x2240mm
|
2925x2040x2240mm
|
|
|
Net weight
|
5000kg
|
5100kg
|
