Detailed description
|
Processing width
|
40-1300mm
|
|
|
Processing thickness
|
3-110mm
|
|
|
Processing length
|
≥300mm
|
|
|
Horizontal belt speed
|
3-18m/s
|
|
|
Longitudinal belt speed
|
3-16m/s
|
|
|
Horizontal belt size ( W x P )
|
150x4800mm
|
|
|
Longitudinal belt size ( W x P )
|
1330x2200mm
|
|
|
Lining size ( W x P )
|
140x4350mm
|
|
|
Conveyor ( W x P )
|
1300x4470mm
|
|
|
Motor power (KW)
|
Horizontal sand frame
|
15
|
|
Vertical sand frame
|
15
|
|
|
Conveyor
|
2.2
|
|
|
Vacuum adsorption device
|
5.5
|
|
|
Conveyor bed lift drive
|
0.37
|
|
|
Brush roll
|
0.37
|
|
|
Compressed air
|
Working pressure
|
0.55Mpa
|
|
Consumption
|
0.7M3/min
|
|
|
Optional dust removal device
|
Air intake
|
9500m3/h
|
|
Static pressure
|
1300Pa
|
|
|
Suction wind speed
|
25-30m/s
|
|
|
Dimensions (L x W x H)
|
2600x2500x2230mm
|
|
|
Net weight
|
4300kg
|
|
